OPP Labeling Machine PET Bottle Labeling
OPP hot melt glue labeling machine is the newest continuous operation of the labeling machine. The mainly used for container labeling cylindrical shape of detergents, beverages, mineral water, food etc. The material of label is using environmentally material of OPP films. It can be automatically oxidative decomposition and reduce production costs by more than 30 percent. Labeling machine is control by PLC touch screen, all electric eye is using imported advanced configuration. This labeling machine with high speed, high accuracy, stable performance, easy to operate and look elegant appearance.
Product Description
OPP hot melt glue labeling machine is the newest continuous operation of the labeling machine.
The mainly used for container labeling cylindrical shape of detergents, beverages, mineral water, food etc. The material of label is using environmentally material of OPP films. It can be automatically oxidative decomposition and reduce production costs by more than 30 percent.
Labeling machine is control by PLC touch screen, all electric eye is using imported advanced configuration. This labeling machine with high speed, high accuracy, stable performance, easy to operate and look elegant appearance.
Detailed Images
Machine Parameters
Model | OPP-100 | OPP-200 | OPP-300 | OPP-400 |
Speed of labeling | 6000BPH | 8000BPH-12000BPH | 15000BPH-18000BPH | 20000BPH-24000BPH |
Power | AC 3ψ380V50Hz | |||
Efficiency | ≥99.5 | ≥99.5 | ≥99.5 | ≥99.5 |
Accuracy of labeling | ±1mm | ±1mm | ±1mm | ±1mm |
Diameter of bottle | 40-110mm | 40-100mm | 40-100mm | 40-100mm |
Material of bottle | Glass, Metal, Plastic | Glass, Metal, Plastic | Glass, Metal, Plastic | Glass, Metal, Plastic |
Shape | Round | Round | Round | Round |
Label material | OPP,BOPP,PAPER | OPP,BOPP,PAPER | OPP,BOPP,PAPER | OPP,BOPP,PAPER |
Label thickness | 0.035-0.05mm | 0.035-0.05mm | 0.035-0.05mm | 0.035-0.05mm |
Label height | 40mm-180mm | 40mm-150mm | 40mm-180mm | 40mm-150mm |
Inside diameter of paper tube | 6inch | 6inch | 6inch | 6inch |
Air source | 0.5Mpa | 0.5Mpa | 0.5Mpa | 0.5Mpa |
Rated power | 10KW | 10KW | 12kw | 12kw |
Machine size | 3176L*1500W*2050H(mm) | 5000L*1600W*2000H(mm) | ||
Weight | 2000kg | 2500kg | 3200kg | 3500kg |
Machine Configuration:
Fully enclosed Host | Door stop |
send bottles | Screw or star wheel |
Feeding bottle | cylinder |
Separate bottle | Stars Wheel |
Sending label | servo encoder control |
Illumination | LED, top + bottom access operation lamp lights + electrical control box overhaul lights |
Fixed feeding shelf | Removable standard planar fast. (Optional double frame) |
Touch screen | single touch |
Cabinet work | Column cabinet manually unscrew the formula |
Corrective devices | Germany E + L |
Alarm system | warning light & buzzer, lack of material, marked off, open the door |
Label system | Physical adjustable friction brake feed |
Transmission systems | machine connections, independent label transmission |
Our Services
Q:Are you a manufacturer or trade company?
A:We are a manufacturer in beverage machine field more than 15 years, located at Jinfeng town,zhangjiagang,2 hours from Shanghai,1 hour from Wuxi by car. We will pick you up to visit our factory.
Q:What about the delivery time?
A:Usually 40 Working days
Q:What about the machine’s capacity?
A:2000-20000 bottles in 500ml per hour.
Q:The after-sale service
A:24 months warranty.
solve basic questions by telephone, email, whatsapp, wechat and video call.
Engineer will go to buyer’s factory to install, test machines, and train buyer’s staff how to operate, maintain machines.
