PET Bottle Soft Drink Filling machine (3 in 1)

1.High filling speed and mass flow rate, high precision of filling valve and control of liquids level is accurate and without loss.
2.The carbonated drinks filling machine is carried perfect CIP control loop and program and cleaning devices on the spot.
3.The filling machine capping head is adopted magnetic-constant-torque device to ensure the high capping quality and without damages


Detailed Images

Machine Parameters

Main features :

1.Washing Part

          All 304 stainless steel rinser heads, water spray style inject design, more save water consumption & more clean, 304 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing, 304 stainless steel washing pumps

2.Filling part

         Isobaric filling , & filling smoothly & steadily

          The centering oriented adopts guide rod with special bottle neck holding

          Filling temperature:0~4℃

         All 316 stainless steel contact parts & liquid tank, fine polish, easy to clean

3. Capping part:

         Place & capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping

       All 304 stainless steel construction

      No bottle no capping and Automatic stop when lack of bottle

Project Name: Carbonated Soft Drink Filling Machine
Model DXGF 40-40-10
Washing Nos 40
Filling Nos 40
Capping Nos 10
Capacity(BPH) 12000
Suitable bottle and cap PET circular or square with screw cap
Bottle Volume 150ml to 2.5Ltr (Customized)
Bottle diameter(mm) Dia50-Dia115mm
Bottle heighter 160-320mm
Compress air pressure(Mpa) 0.3-0.4Mpa
Washing medium Aspetic water
Rinsing pressure(Mpa) >0.06Mpa<0.2Mpa
Filling temperature  0~4℃
Filling theory Isobaric filling
Total powder 5.5KW
Dimension  (meter) 4.43*3.28*2.65M


Production Lines Flow Chart

Water Treatment System

Water Treatment System

Water purification machine to treat fresh water for pure, drinking, mineral water. Our plant could make drinking water, mineral water, pure water and potable water from the water sources: Ground, spring, well, river, brackish, lake water and etc.
Raw water source: Bore whole, river, well, mountain spring, lake, etc

View Details
Blowing Molding System

Blowing Molding System

With our automatic blow molding machine, you can effortlessly create PET plastic containers and bottles in various shapes. It is widely utilized in the production of carbonated beverage bottles, mineral water containers, pesticide bottles, edible oil containers, cosmetic bottles, wide-mouth containers, and hot-fill bottles.

View Details
Automatic Labeling Machine

Automatic Labeling Machine

The thermal shrink sleeve machine has adopted an innovative double driving structure as its advanced driving mechanism. With four-wheel driving, it achieves self-centering and equal pressure distribution across all four wheels, facilitating the seamless, steady, and rapid label transfer.

View Details
Shrink Wrapping Machine

Shrink Wrapping Machine

Automatic Linear high speed film shrink wrapping machine is suitable for wrapping of such products as pop-top,mineral water ,bottles.beer,drinks etc without bottom tray ,working with PE film shrink tunnel to pack the goods perfectly ,this style machine is suitable for capacity over 12,000bph line .

View Details
Water Beverage Soft Drinks Bottle Carton Box Packaging Machine

Water Beverage Soft Drinks Bottle Carton Box Packaging Machine

It can open vertical cardboard and correct the right-angle automatically. Automatic carton opening machine is a case packer that deals with unpacking ,carton flexing and packing. This machine adopts PLC and touch screen to control. As a result, it is more convenient to operate and manage. Additionally, it can reduce labour input and lower labour intensity. It is the ideal choice of the automation producing lines. It will greatly reduce the cost of packing. Hot melt adhesive can also be utilized in this machine.

View Details
Automatic Pallet Stretch Wrapping Machine

Automatic Pallet Stretch Wrapping Machine

In short, the pre stretching wrapping machine is to stretch the film in advance in the mold base device when wrapping the film, so as to improve the stretching proportion as much as possible, use the wrapping film to a certain extent, save materials and save packaging costs for users. Pre stretching wrapping machine can save wrapping film to a certain extent

View Details
Palletizer Machine

Palletizer Machine

According to a certain order, palletizer stacks the packed products(in box, bag, bucket) to the corresponding empty pallets through a series of mechanical actions so as to facilitate handling and transporting batches of products to improve production efficiency. Meanwhile it can use stack layer pad to improve the stability of each stack layer. Various forms designed to meet different palletizing requirements.

View Details
Carbonated Soft Drinks Mixing  System

Carbonated Soft Drinks Mixing System

Beverage CO2 mixer, used in the production of acidification and mixing of various gas contained beverages(water, syrup,Carbon dioxide), such as citric drink, coke, juice etc. aerated water, is the main equipment in a drink production line(especially the key equipment in the middle and high grade of drink production).

View Details

Why Choose US

  1. We are the direct manufacturer, we have been engaged in development and manufacturing of beverages and liquid food filling machines for more than 10 years, our plant area of 4000m2, with independent property rights.
  2. We have a professional team for exporting, we can supply stable quality faster delivery and clearly communications.
  3. We can make custom manufacturing, our technical team can design different size and products to meet your special requirements.
  4. Without getting customer’s approve, we will not ship the equipment hastily, every equipment will be tested continuously 24 hours before loading, we will control every step strictly in the process of manufacture.
  5. All of our equipment will have 12 months guarantee, and we will supply techinical servie all equipment life.
  6. We will supply the spare parts fast and with cost price.
