Sheet type carton wrapping machine 12,000-24,000 boxes per hour

Wraparound carton packer machine uses up to 20% less corrugated material than conventional regular slotted case packing systems. The system collates the products, loads the corrugated cases or trays, and closes them with hot-melt glue. it provides tight packages minimizing the need for partitions while protecting glass containers from damage. If needed, the system options allow for automatic insertion of partitions, dividers, or pads to increase product protection.

Video

Detailed Images

Machine Parameters

Main features :

1.resembles an arch structure, which can provide impact protection and shock absorption, and has good mechanical properties.
2. has many good protection functions for packaged items. For example, moisture-proof, heat dissipation, easy to handle and so on.
3.Transportation costs are low, and it is easy to achieve the mechanisation and automation of packaging and transportation.
4. Changes in specifications and dimensions are easy to realise and can be quickly adapted to the packaging of all kinds of articles.
5. Sealing and strapping are convenient and easy to automate operations.
6. can adapt to various types of cartons of decorative printing, can well solve the problem of commodity protection and promotion.
7. can greatly expand its scope of use by combining with various coverings or moisture-proof materials.
The shape of the packed box is beautiful, and the product grade and appearance image can be further improved.

PROJECT Wrap around carton packing machine
Applicable Container Plastic bottle, Glass bottle, Tins and Cans
Product Size 250ML-2000ML
Container Diameter 57-100(or larger)mm
Capacity 25 Cartons/per min
Machine Dimension(L*W*H) L6285*W2582*H2115mm
Carton Size 500 < L+W+H< 1000
Hot Melt Glue Solidify 1.5-2s
Working Pressure 0.4-0.7Mpa
Power 15KW
Weight 4000 KG

Production Lines Flow Chart


Warning: Invalid argument supplied for foreach() in /home/customer/www/sinopakmachinery.com/public_html/wp-content/themes/iwonder/functions.php on line 253

Why Choose US

  1. We are the direct manufacturer, we have been engaged in development and manufacturing of beverages and liquid food filling machines for more than 10 years, our plant area of 4000m2, with independent property rights.
  2. We have a professional team for exporting, we can supply stable quality faster delivery and clearly communications.
  3. We can make custom manufacturing, our technical team can design different size and products to meet your special requirements.
  4. Without getting customer’s approve, we will not ship the equipment hastily, every equipment will be tested continuously 24 hours before loading, we will control every step strictly in the process of manufacture.
  5. All of our equipment will have 12 months guarantee, and we will supply techinical servie all equipment life.
  6. We will supply the spare parts fast and with cost price.
