XGF50-50-15 24000BPH Automatic Plastic Bottle Washing /Filling Capping Machine

The whole process is automatic, Filling way using the gravity or micro pressure filling, make the speed is faster and more stable, so with the same model our machine output is higher and more efficient.

Video

Detailed Images

Machine Parameters

Main features :

  1. The machine has compact structure, perfect control system, convenient operation and high automation
  2. Parts in contact with materials are made of imported high quality stainless steel, no process dead Angle, easy to clean
  3. High precision, high speed quantitative filling valve, accurate liquid level without liquid loss, to ensure excellent filling quality
  4. The capping head adopts constant torque device to ensure the capping quality
  5. Adopt efficient capping management system, with perfect cap loading  technology and protection device
  6. It is not necessary to adjust the height of the equipment to change the bottle size. It can be realized by replacing the star wheel of the bottle, which is simple and convenient to operate
  7. The filling system adopts the bottle – bottling technology to avoid the secondary pollution of the bottle mouth
  8. The control system has the functions of automatic water level control, missing cap detection, automatic stop of bottle flushing and output counting
  9. The bottle washing system adopts the efficient cleaning spray nozzle produced by American spray Company technology, which can be cleaned to every place in the bottle
  10. The main electrical components, electronic control valves, frequency converters and so on are imported parts to ensure the excellent performance of the whole machine
  11. All components of pneumatic system adopt international famous products.This machine integrated three function: 1. Rinse the empty pet bottle, 2. filling the rinsed bottles, 3. capping the filled bottles
Project Name: Drinking Water Filling Machine
Model XGF 50-50-15
Washing Nos 50
Filling Nos 50
Capping Nos 15
Capacity(BPH) 24000
Suitable bottle and cap PET circular or square with screw cap
Bottle Volume 150ml to 2.5Ltr (Customized)
Bottle diameter(mm) Dia50-Dia115mm
Bottle heighter 160-320mm
Compress air pressure(Mpa) 0.3-0.4Mpa
Washing medium Aspetic water
Rinsing pressure(Mpa) >0.06Mpa<0.2Mpa
Filling temperature Room temperature
Filling theory By gravity
Total powder 7.5KW
Dimension  (meter) 4.72*3.55*2.75M



Production Lines Flow Chart

Water treatment system

Water treatment system

  1. Utilizing the world’s foremost Reverse Osmosis technology, our system integrates optimized design and meticulous production techniques.
  2. Featuring an all-in-one compact design, crafted from carefully selected materials, our system epitomizes efficiency and elegance.
  3. Achieving a remarkable salt rejection rate exceeding 99%, the system ensures exceptional water purity.
  4. With stable performance, unparalleled reliability, and an innovative design, our system requires minimal cleaning, staying current with industry trends.
  5. Incorporating online conductivity monitoring, the system guarantees consistently high-quality water output.
  6. Equipped with an automatic control system, our system is designed for easy installation, operation, and maintenance, all within a compact footprint.
  7. Meticulously designed with precision techniques and carefully chosen materials, our system reflects engineering excellence.
  8. Boasting an extended lifetime, low energy consumption, and minimal maintenance costs, our system offers a sustainable and cost-effective solution for your water purification needs.
View Details
Blow molding system

Blow molding system

The fully automatic blow molding machine is designed for the production of PET plastic containers and bottles in a versatile range of shapes. It finds widespread application in manufacturing carbonated bottles, mineral water containers, pesticide bottles, oil bottles, cosmetics packaging, wide-mouth bottles, and hot-fill bottles, among other products. Its adaptability makes it a reliable choice for diverse packaging needs across various industries.

View Details
Automatic labeling machine

Automatic labeling machine

The OPP hot melt glue labeling machine represents the latest in continuous labeling operations. Primarily designed for labeling cylindrical containers such as detergents, beverages, mineral water, and food products, this machine utilizes environmentally friendly OPP films as label material. It features automatic oxidative decomposition, resulting in a reduction of production costs by over 30 percent. Controlled by a PLC touch screen, the labeling machine incorporates imported advanced electric eye configurations for precise operation. With high speed, accuracy, stable performance, ease of operation, and an elegant appearance, this labeling machine is an advanced solution for efficient and aesthetic labeling.

View Details
Shrink wrapping machine

Shrink wrapping machine

Tailored for mass production packaging lines, this system is designed to accommodate products of varying widths and heights. Additionally, it features a contact function specifically for efficient packaging of smaller-sized products. The versatility of the system makes it well-suited for diverse product dimensions, ensuring an efficient and adaptable solution for high-volume packaging operations.

View Details
Palletizer machine

Palletizer machine

In accordance with a specified order, the palletizer performs a sequence of mechanical actions, stacking packed products (in boxes, bags, buckets) onto designated empty pallets. This process is designed to streamline the handling and transportation of product batches, thereby enhancing overall production efficiency. Additionally, the palletizer can incorporate stack layer pads to enhance the stability of each layer in the stack. Its versatile design caters to various forms, ensuring it meets different palletizing requirements based on specific needs.

View Details

Why Choose US

  1. We are the direct manufacturer, we have been engaged in development and manufacturing of beverages and liquid food filling machines for more than 10 years, our plant area of 4000m2, with independent property rights.
  2. We have a professional team for exporting, we can supply stable quality faster delivery and clearly communications.
  3. We can make custom manufacturing, our technical team can design different size and products to meet your special requirements.
  4. Without getting customer’s approve, we will not ship the equipment hastily, every equipment will be tested continuously 24 hours before loading, we will control every step strictly in the process of manufacture.
  5. All of our equipment will have 12 months guarantee, and we will supply techinical servie all equipment life.
  6. We will supply the spare parts fast and with cost price.
