3-5 Gallon Water Filling Machine

Home > Products > Bottle Water Filling Machine > 3-5 Gallon Water Filling Machine

Production Reliability – anytime and anywhere

A bottled water filling machine line is used to filling mineral water or purified water into a PET bottle from 200ml-2000ml. Different models can satisfy the various requirement of output from 2000BPH to 36000BPH. The machine combines washing, filling, and capping three functions in a body; the whole process is automatic, suitable for PET bottles, plastic bottle filling mineral water, and pure water. Loading way using gravity or micro pressure filling makes the speed faster and more stable, so with the same model, our machine output is higher and more efficient. The machine adopts an advanced Mitsubishi programmable controller (PLC) to control the machine to run automatically, interworking with inverter running more stable and reliable. The photoelectric sensor detects all part running state, with a high degree of automation, easy operation.

900BPH 5 Gallon Water Bottle Filling Machine Line Price

All-in-one machine unit for 3-5 gallon water barrels, Combines washing, drying, filling, and capping functions, Multi-step washing process includes alkaline and disinfecting water, Efficiently recycles water in closed-loop system, Precisely controlled by PC with safety mechanisms, Ensures thorough cleaning and production safety

Model: QGF-900
Capacity(BPH): 900
Bottle Volume: 3 & 5 Gallon
Compress air pressure(Mpa): 0.3-0.7Mpa
Total powder: 6.2kw
Overall dimensions: 3.8*2.8m

600BPH 5 Gallon Water Bottle Filling Machine Line

Core functions: washing, drying, filling, capping, Produces 3-5 gallon barrels of drinking water, Alkaline liquid for thorough cleaning, Disinfecting water for interior and exterior cleansing, Efficiently recycles water, PC-controlled for precise monitoring, Safety mechanisms for interlocking

Model: QGF-600
Capacity (for 5 gallon): 600bph
Bottle Volume: 3 & 5 Gallon
Compress air pressure(Mpa): 0.3-0.7Mpa
Total powder: 5.2kw
Overall dimensions: 3.1*2.5m

450BPH 5 Gallon Water Bottle Filling Machine Line Price

Integrates rinsing, filling, capping, Automatic loading, Bottle washers, decapper, Heating shrink tunnel, Conveyor, control system

Model: QGF-450
Capacity (for 5 gallon): 450bph
Bottle Volume: 3 & 5 Gallon
Compress air pressure(Mpa): 0.3-0.7Mpa
Total powder: 4.5KW
Overall dimensions: 2.8*2.15m

300BPH 5 Gallon Water Bottle Filling Machine Line Price

The series of machine integrate rinsing, contain rinser-filler-capper monoblock, automatic loading machine, bottle outside washer, bottle inside washer, decapper, heating shrink tunnel, conveyor system, complete line control system.

Model: QGF-300
Capacity (for 5 gallon): 300bph
Bottle Volume: 3 & 5 Gallon
Compress air pressure(Mpa): 0.3-0.7Mpa
Total powder: 3.8KW
Overall dimensions: 2.5*1.9m

100BPH 150BPH 5 Gallon Water Bottle Filling Machine Line

Series integrates rinsing, monoblock, Automatic loading, decapper, Bottle washers, shrink tunnel, Conveyor, control system

Model: QGF-100
Capacity (for 5 gallon): 60-150bph
Bottle Volume: 3 & 5 Gallon
Compress air pressure(Mpa): 0.3-0.7Mpa
Total powder: 1.5KW
Overall dimensions: 2.3*1.9m

5 Gallon Water Bottle Filling Machine Line Price

Comprehensive machine series, Integrates rinsing, monoblock, Automatic loading, decapper, Exterior and interior washers, Heating shrink tunnel, conveyor, Complete line control system

Bottle volume: 3 & 5 Gallon
Compressor air: 0.3-0.7Mpa
Air consumption: 0.37 m3/min
Rinsing pressure: >0.06Mpa <0.2Mpa

Automatic Linear Type Washing Filling Capping Machine For 3-5 Gallons Barrel

As a professional China Linear filling machine automatic filling machine expert, we provide barrel filling machine big plastic bottle washing filling capping machine

Volume(Gallon): From 3 to 5 gallon
Barrel size(mm): Dia270*490

3-5 Gallon water filling machine

Comprehensive machine series, Integrates essential functions, Includes rinsing, monoblock, Automatic loading, decapping, Exterior, interior washing, Heating tunnel, conveyor, Line control system

Bottle volume: 3 & 5 Gallon
Compressor air: 0.3-0.7Mpa
Air consumption: 0.37 m3/min
Rinsing pressure: >0.06Mpa <0.2Mpa
